Space Grade Ava-MRAM™

Boot Memory

Discrete Ava-MRAM

Avalanche’s Persistent SRAM (P-SRAM™) is non-volatile memory utilizing advanced STT-MRAM with simplified SRAM compatible read/write timings and no need for wait states or wear leveling as the data is immediately available when written. Architected for high reliability and radiation resilience, the products on this page and the pin-compatible extended qualification and screening options are ideal for high reliability applications such as aerospace and defense.

Defining Space Grade Technical documentation

Avalanche Technology electronic chip design illustration.

Industry Leading
Density: 1Gb to 8Gb
Low Power: 50mA/Gb active
Write Cycle Endurance: 10¹⁶
Design Simplicity
Flexible yet robust write protection, providing terrestrial design simplicity compared to legacy memory.
Multiple Mission Support
Support for multiple mission images provides true in situ adaptability, software-defined satellites.

The foundation of Trusted Boot

Boot memory holds the golden image, boot code, bitstreams, cryptographic keys, and configuration data that a platform needs to start in its intended state. Those assets make memory part of the system’s root-of-trust architecture.

From component properties to a trusted boot solution

AvalancheSpace Grade memoryFive criteria working together

SolutionTrusted boot foundation

Golden image
Boot code
Bitstreams
Keys & configuration

Memory preserves these assets; system-level verification and authentication establish trust.

Scalable Qual Levels

Qual	Package	Temp	LET (MeV-cm2/mg)	TID (Krad)	Burn In	Qual Standards
QML	Ceramic/Plastic	-55°C to 125°C	100+**	300+*	Custom	QML-M to V
PEMS I, II, III	Plastic	-40°C to 125°C	≤37-75**	300*	Custom	NASA-INST-001
Space Grade-R	Plastic	-40°C to 125°C	100+**	300+*	168 Hrs	JESD47H.01
Space Grade-E	Plastic	-40°C to 125°C	≤75*	100*	168 Hrs	JESD47H.01
Space Grade	Plastic	-40°C to 125°C	≤37-75*	75-100*	48 Hrs	JESD47H.01

QML

Package: Ceramic/Plastic
Temp: -55°C to 125°C
LET (MeV-cm2/mg): 100+**
TID (Krad): 300+*
Burn In: Custom
Qual Standards: QML-M to V

PEMS I, II, III

Package: Plastic
Temp: -40°C to 125°C
LET (MeV-cm2/mg): ≤37-75**
TID (Krad): 300*
Burn In: Custom
Qual Standards: NASA-INST-001

Space Grade-R

Package: Plastic
Temp: -40°C to 125°C
LET (MeV-cm2/mg): 100+**
TID (Krad): 300+*
Burn In: 168 Hrs
Qual Standards: JESD47H.01

Space Grade-E

Package: Plastic
Temp: -40°C to 125°C
LET (MeV-cm2/mg): ≤75*
TID (Krad): 100*
Burn In: 168 Hrs
Qual Standards: JESD47H.01

Space Grade

Package: Plastic
Temp: -40°C to 125°C
LET (MeV-cm2/mg): ≤37-75*
TID (Krad): 75-100*
Burn In: 48 Hrs
Qual Standards: JESD47H.01

* Radiation performance tested during Qualification phase.
** All components are guaranteed to come from the same lot. Radiation/Qual report for that lot/individual die available through the datapack.
